360° Visibility Bundle
The 360° Visibility Bundle delivers expanded camera coverage and in-cab visibility to improve driver safety on the road and works seamlessly with Samsara’s AI Multicam or HD Camera Connector.
Flexible coverage tailored to your unique vehicle configuration
High-definition video clarity
All cameras and the in-cab monitor support 1080p HD resolution for sharp, detailed footage.
Audio-ready configuration
Built-in microphones can be used to capture audio for added context where needed.
Built for the road
Slim, rugged camera designs support exterior or interior mounting and stand up to harsh operating environments.
Driver-centric monitor
In-cab monitor provides configurable viewing arrangements, and, when paired with AI Multicam, supports dynamic visibility.
Product specifications
Compatibility | The Cameras and Monitor in the 360° Visibility Bundle are compatible with the following: Samsara AI Multicam (HW-MC-AIM4) Samsara HD Camera Connector (HW-CM-AHD1) |
Add-on accessories | 5m GX12 Female to GX12 Male Cable | CBL-MC-GX5 10m GX12 Female GX12 Male Cable | CBL-MC-GX10 15m GX12 Female GX12 Male Cable | CBL-MC-GX15 |
Side Camera, Mirror Mount HW-MC11 |
Housing Material Plastic Dimensions 2.8in X 2.2in X 2in 72mm X 57mm X 51mm IP Rating IP69K Operating Temperature -30°C to 75°C
Resolution 1080p Horizontal Field of View 112° Vertical Field of View 62° Low Light IR Yes
Built In Microphone Yes
Power Requirements Powered by AIM4 or AHD1 |
Side Camera, Body Mount HW-MC21 |
Housing Material Metal Dimensions 2.8in x 2in x 1.7in 70mm x 51mm x 45mm IP Rating IP69K Operating Temperature -30°C to 75°C
Resolution 1080p Horizontal Field of View 135° Vertical Field of View 90° Low Light IR Yes
Built In Microphone Yes
Power Requirements Powered by AIM4 or AHD1 |
Rear Camera, HW-MC31 |
Housing Material Metal Dimensions 3.1in x 2.4in x 1.9in 78mm x 60.6mm x 48.5mm IP Rating IP69K Operating Temperature -30°C to 75°C
Resolution 1080p Horizontal Field of View 112° Vertical Field of View 62° Low Light IR Yes
Built In Microphone Yes
Power Requirements Powered by AIM4 or AHD1 |
Monitor, HW-MN11 |
Housing Material Plastic Dimensions 7.36in X 5.43in X 1.22in 187mm X 138mm X 31mm Weight 530g IP Rating IP54 Operating Temperature -30°C to 75°C
Auto Dimming Yes Resolution Supports Up To 1080p Video Format AHD/PAL/NTSC
Power Requirements 12-24V 500mA@12V If paired with AIM4, power is directly supplied by the AIM4 |
Flexible self-installation
Install Samsara side and rear cameras and Samsara monitors using either the AI Multicam Hub or the AHD1 Camera Connector. Cameras can be positioned at the rear, on side mirrors or body panels, and even inside the cab if desired.
